Data sheet

Model name

FD20

Working width

up to 3 meters

Area coverage

up to 20 ha per season and crop

Row spacing

Configurable from 22.5 cm to 75 cm

Tools

Configurable from 4 to 8 active rows and 4 to 8 passive rows

Cultures

sugar beets, onions, rapeseed, various vegetables and herbs

Speed

max. 950 m / h

Incline

max. 8% incline and max. 6% side slope

Seed hopper

6-litre capacity

Weight

900 kg including batteries (4 x 35 kg additional weights available)

Working temperature

0 - 40 ° C

Storage temperature

-10 - 50 ° C

Solar cell capacity

1.6 kW

Battery capacity

4.8 kWh

Drive motors

2 x 400 W

Navigation and communication

RTK and cellular or radio

Material

stainless steel: AISI 304, plastic: carbon fibre reinforced nylon

Degree of protection

IP65
